DataTable represents a physical table on disk. More...

#include <duckdb.hpp>

Inheritance diagram for duckdb::DataTable:

Collaboration diagram for duckdb::DataTable:

[legend]

Public Member Functions
	DataTable (AttachedDatabase &db, shared_ptr< TableIOManager > table_io_manager, const string &schema, const string &table, vector< ColumnDefinition > column_definitions_p, unique_ptr< PersistentTableData > data=nullptr)
	Constructs a new data table from an (optional) set of persistent segments.

	DataTable (ClientContext &context, DataTable &parent, ColumnDefinition &new_column, Expression &default_value)
	Constructs a DataTable as a delta on an existing data table with a newly added column.

	DataTable (ClientContext &context, DataTable &parent, idx_t removed_column)
	Constructs a DataTable as a delta on an existing data table but with one column removed.

	DataTable (ClientContext &context, DataTable &parent, idx_t changed_idx, const LogicalType &target_type, const vector< StorageIndex > &bound_columns, Expression &cast_expr)
	Constructs a DataTable as a delta on an existing data table but with one column changed type.

	DataTable (ClientContext &context, DataTable &parent, BoundConstraint &constraint)
	Constructs a DataTable as a delta on an existing data table but with one column added new constraint.

AttachedDatabase &	GetAttached ()

TableIOManager &	GetTableIOManager ()

bool	IsTemporary () const

vector< LogicalType >	GetTypes ()
	Returns a list of types of the table.

const vector< ColumnDefinition > &	Columns () const

void	InitializeScan (ClientContext &context, DuckTransaction &transaction, TableScanState &state, const vector< StorageIndex > &column_ids, optional_ptr< TableFilterSet > table_filters=nullptr)

idx_t	MaxThreads (ClientContext &context) const
	Returns the maximum amount of threads that should be assigned to scan this data table.

void	InitializeParallelScan (ClientContext &context, ParallelTableScanState &state, const vector< ColumnIndex > &column_indexes)

idx_t	NextParallelScan (ClientContext &context, ParallelTableScanState &state, TableScanState &scan_state)

void	Scan (DuckTransaction &transaction, DataChunk &result, TableScanState &state)

void	Fetch (DuckTransaction &transaction, DataChunk &result, const vector< StorageIndex > &column_ids, const Vector &row_ids, idx_t fetch_count, ColumnFetchState &state)
	Fetch data from the specific row identifiers from the base table.

void	FetchCommitted (DataChunk &result, const vector< StorageIndex > &column_ids, const Vector &row_identifiers, idx_t fetch_count, ColumnFetchState &state)

bool	CanFetch (DuckTransaction &transaction, const row_t row_id)
	Returns true, if the transaction can fetch the row ID.

void	InitializeLocalAppend (LocalAppendState &state, TableCatalogEntry &table, ClientContext &context, const vector< unique_ptr< BoundConstraint > > &bound_constraints)
	Initializes appending to transaction-local storage.

void	InitializeLocalStorage (LocalAppendState &state, TableCatalogEntry &table, ClientContext &context, const vector< unique_ptr< BoundConstraint > > &bound_constraints)
	Initializes only the delete-indexes of the transaction-local storage.

void	LocalAppend (LocalAppendState &state, ClientContext &context, DataChunk &chunk, bool unsafe)
	Append a DataChunk to the transaction-local storage of the table.

void	FinalizeLocalAppend (LocalAppendState &state)
	Finalizes a transaction-local append.

void	LocalAppend (TableCatalogEntry &table, ClientContext &context, DataChunk &chunk, const vector< unique_ptr< BoundConstraint > > &bound_constraints, Vector &row_ids, DataChunk &delete_chunk)
	Append a chunk to the transaction-local storage of this table and update the delete indexes.

void	LocalAppend (TableCatalogEntry &table, ClientContext &context, DataChunk &chunk, const vector< unique_ptr< BoundConstraint > > &bound_constraints)
	Appends to the transaction-local storage of this table.

void	LocalWALAppend (TableCatalogEntry &table, ClientContext &context, DataChunk &chunk, const vector< unique_ptr< BoundConstraint > > &bound_constraints)
	Append a chunk to the transaction-local storage of this table.

void	LocalAppend (TableCatalogEntry &table, ClientContext &context, ColumnDataCollection &collection, const vector< unique_ptr< BoundConstraint > > &bound_constraints, optional_ptr< const vector< LogicalIndex > > column_ids)
	Append a column data collection with default values to the transaction-local storage of this table.

void	LocalMerge (ClientContext &context, OptimisticWriteCollection &collection)
	Merge a row group collection into the transaction-local storage.

PhysicalIndex	CreateOptimisticCollection (ClientContext &context, unique_ptr< OptimisticWriteCollection > collection)

OptimisticWriteCollection &	GetOptimisticCollection (ClientContext &context, const PhysicalIndex collection_index)
	Returns the optimistic row group collection corresponding to the index.

void	ResetOptimisticCollection (ClientContext &context, const PhysicalIndex collection_index)
	Resets the optimistic row group collection corresponding to the index.

OptimisticDataWriter &	GetOptimisticWriter (ClientContext &context)
	Returns the optimistic writer of the corresponding local table.

unique_ptr< TableDeleteState >	InitializeDelete (TableCatalogEntry &table, ClientContext &context, const vector< unique_ptr< BoundConstraint > > &bound_constraints)

idx_t	Delete (TableDeleteState &state, ClientContext &context, Vector &row_ids, idx_t count)
	Delete the entries with the specified row identifier from the table.

unique_ptr< TableUpdateState >	InitializeUpdate (TableCatalogEntry &table, ClientContext &context, const vector< unique_ptr< BoundConstraint > > &bound_constraints)

void	Update (TableUpdateState &state, ClientContext &context, Vector &row_ids, const vector< PhysicalIndex > &column_ids, DataChunk &data)
	Update the entries with the specified row identifier from the table.

void	UpdateColumn (TableCatalogEntry &table, ClientContext &context, Vector &row_ids, const vector< column_t > &column_path, DataChunk &updates)

void	AppendLock (DuckTransaction &transaction, TableAppendState &state)
	Fetches an append lock.

void	InitializeAppend (DuckTransaction &transaction, TableAppendState &state)
	Begin appending structs to this table, obtaining necessary locks, etc.

void	Append (DataChunk &chunk, TableAppendState &state)
	Append a chunk to the table using the AppendState obtained from InitializeAppend.

void	FinalizeAppend (DuckTransaction &transaction, TableAppendState &state)
	Finalize an append.

void	CommitAppend (transaction_t commit_id, idx_t row_start, idx_t count)
	Commit the append.

void	WriteToLog (DuckTransaction &transaction, WriteAheadLog &log, idx_t row_start, idx_t count, optional_ptr< StorageCommitState > commit_state)
	Write a segment of the table to the WAL.

void	RevertAppend (DuckTransaction &transaction, idx_t start_row, idx_t count)

void	RevertAppendInternal (idx_t start_row)

void	ScanTableSegment (DuckTransaction &transaction, idx_t start_row, idx_t count, const std::function< void(DataChunk &chunk)> &function)

void	MergeStorage (RowGroupCollection &data, optional_ptr< StorageCommitState > commit_state)
	Merge a row group collection directly into this table - appending it to the end of the table without copying.

ErrorData	AppendToIndexes (optional_ptr< TableIndexList > delete_indexes, DataChunk &table_chunk, DataChunk &index_chunk, const vector< StorageIndex > &mapped_column_ids, row_t row_start, const IndexAppendMode index_append_mode)

void	RevertIndexAppend (TableAppendState &state, DataChunk &chunk, row_t row_start)
	Revert a previous append made to indexes in a chunk with the row ids [row_start, ..., row_start + chunk.size()].

void	RevertIndexAppend (TableAppendState &state, DataChunk &chunk, Vector &row_identifiers)
	Revert a previous append made to indexes with the given row-ids.

void	RemoveFromIndexes (const QueryContext &context, Vector &row_identifiers, idx_t count, IndexRemovalType removal_type, optional_idx checkpoint_id=optional_idx())
	Remove the row identifiers from all the indexes of the table.

void	SetAsMainTable ()

void	SetAsDropped ()

bool	IsMainTable () const

bool	IsRoot () const

string	TableModification () const

unique_ptr< BaseStatistics >	GetStatistics (ClientContext &context, const StorageIndex &column_id)
	Get statistics of a physical column within the table.

unique_ptr< BlockingSample >	GetSample ()
	Get table sample.

void	SetDistinct (column_t column_id, unique_ptr< DistinctStatistics > distinct_stats)
	Sets statistics of a physical column within the table.

unique_ptr< StorageLockKey >	GetCheckpointLock ()
	Obtains a lock during a checkpoint operation that prevents other threads from reading this table.

void	Checkpoint (TableDataWriter &writer, Serializer &serializer)
	Checkpoint the table to the specified table data writer.

void	CommitDropTable ()

void	CommitDropColumn (const idx_t column_index)

idx_t	ColumnCount () const

idx_t	GetTotalRows () const

vector< ColumnSegmentInfo >	GetColumnSegmentInfo (const QueryContext &context)

bool	CreateIndexScan (TableScanState &state, DataChunk &result)
	Scans the next chunk for the CREATE INDEX operator.

bool	IndexNameIsUnique (const string &name)

unique_ptr< ConstraintState >	InitializeConstraintState (TableCatalogEntry &table, const vector< unique_ptr< BoundConstraint > > &bound_constraints)
	Initialize constraint verification state.

void	VerifyAppendConstraints (ConstraintState &constraint_state, ClientContext &context, DataChunk &chunk, optional_ptr< LocalTableStorage > local_storage, optional_ptr< ConflictManager > manager)
	Verify constraints with a chunk from the Append containing all columns of the table.

shared_ptr< DataTableInfo > &	GetDataTableInfo ()

void	BindIndexes (ClientContext &context)

bool	HasIndexes () const

bool	HasUniqueIndexes () const

bool	HasForeignKeyIndex (const vector< PhysicalIndex > &keys, ForeignKeyType type)

void	SetIndexStorageInfo (vector< IndexStorageInfo > index_storage_info)

void	VacuumIndexes ()

void	VerifyIndexBuffers ()

void	CleanupAppend (transaction_t lowest_transaction, idx_t start, idx_t count)

void	Destroy ()

string	GetTableName () const

void	SetTableName (string new_name)

TableStorageInfo	GetStorageInfo ()

idx_t	GetRowGroupSize () const

void	VerifyUniqueIndexes (TableIndexList &indexes, optional_ptr< LocalTableStorage > storage, DataChunk &chunk, optional_ptr< ConflictManager > manager)
	Verify any unique indexes using optional delete indexes in the local storage.

void	AddIndex (const ColumnList &columns, const vector< LogicalIndex > &column_indexes, const IndexConstraintType type, IndexStorageInfo index_info)

void	AddIndex (unique_ptr< Index > index)
	AddIndex moves an index to this table's index list.

vector< PartitionStatistics >	GetPartitionStats (ClientContext &context)
	Returns a list of the partition stats.

Public Member Functions inherited from duckdb::enable_shared_from_this< DataTable >
shared_ptr< DataTable >	shared_from_this ()

shared_ptr< DataTable const >	shared_from_this () const

Static Public Member Functions
static ErrorData	AppendToIndexes (TableIndexList &indexes, optional_ptr< TableIndexList > delete_indexes, DataChunk &table_chunk, DataChunk &index_chunk, const vector< StorageIndex > &mapped_column_ids, row_t row_start, const IndexAppendMode index_append_mode, optional_idx active_checkpoint)

Public Attributes
AttachedDatabase &	db
	A reference to the database instance.

Private Member Functions
void	VerifyNewConstraint (LocalStorage &local_storage, DataTable &parent, const BoundConstraint &constraint)
	Verify the new added constraints against current persistent&local data.

void	VerifyUpdateConstraints (ConstraintState &state, ClientContext &context, DataChunk &chunk, const vector< PhysicalIndex > &column_ids)
	Verify constraints with a chunk from the Update containing only the specified column_ids.

void	VerifyDeleteConstraints (optional_ptr< LocalTableStorage > storage, TableDeleteState &state, ClientContext &context, DataChunk &chunk)
	Verify constraints with a chunk from the Delete containing all columns of the table.

void	InitializeScanWithOffset (DuckTransaction &transaction, TableScanState &state, const vector< StorageIndex > &column_ids, idx_t start_row, idx_t end_row)

void	RebuildIndexes ()
	Rebuild all indexes after vacuuming changed rowid's (used with vacuum_rebuild_indexes setting).

void	VerifyForeignKeyConstraint (optional_ptr< LocalTableStorage > storage, const BoundForeignKeyConstraint &bound_foreign_key, ClientContext &context, DataChunk &chunk, VerifyExistenceType type)

void	VerifyAppendForeignKeyConstraint (optional_ptr< LocalTableStorage > storage, const BoundForeignKeyConstraint &bound_foreign_key, ClientContext &context, DataChunk &chunk)

void	VerifyDeleteForeignKeyConstraint (optional_ptr< LocalTableStorage > storage, const BoundForeignKeyConstraint &bound_foreign_key, ClientContext &context, DataChunk &chunk)

Private Attributes
shared_ptr< DataTableInfo >	info
	The table info.

vector< ColumnDefinition >	column_definitions
	The set of physical columns stored by this DataTable.

mutex	append_lock
	Lock for appending entries to the table.

shared_ptr< RowGroupCollection >	row_groups
	The row groups of the table.

atomic< DataTableVersion >	version
	The version of the data table.

Additional Inherited Members
Protected Member Functions inherited from duckdb::enable_shared_from_this< DataTable >
	enable_shared_from_this (enable_shared_from_this const &) noexcept

enable_shared_from_this &	operator= (enable_shared_from_this const &) noexcept

Detailed Description

DataTable represents a physical table on disk.

Member Function Documentation

◆ Scan()

void duckdb::DataTable::Scan	(	DuckTransaction &	transaction,
		DataChunk &	result,
		TableScanState &	state
	)

Scans up to STANDARD_VECTOR_SIZE elements from the table starting from offset and store them in result. Offset is incremented with how many elements were returned. Returns true if all pushed down filters were executed during data fetching

◆ CreateOptimisticCollection()

PhysicalIndex duckdb::DataTable::CreateOptimisticCollection	(	ClientContext &	context,
		unique_ptr< OptimisticWriteCollection >	collection
	)

Create an optimistic row group collection for this table. Used for optimistically writing parallel appends. Returns the index into the optimistic_collections vector for newly created collection.

◆ UpdateColumn()

void duckdb::DataTable::UpdateColumn	(	TableCatalogEntry &	table,
		ClientContext &	context,
		Vector &	row_ids,
		const vector< column_t > &	column_path,
		DataChunk &	updates
	)

Update a single (sub-)column along a column path The column_path vector is a path towards a column within the table i.e. if we have a table with a single column S STRUCT(A INT, B INT) and we update the validity mask of "S.B" the column path is: 0 (first column of table) -> 1 (second subcolumn of struct) -> 0 (first subcolumn of INT) This method should only be used from the WAL replay. It does not verify update constraints.

◆ RevertAppend()

void duckdb::DataTable::RevertAppend	(	DuckTransaction &	transaction,
		idx_t	start_row,
		idx_t	count
	)

Revert a set of appends made by the given AppendState, used to revert appends in the event of an error during commit (e.g. because of an I/O exception)

◆ AppendToIndexes()

static ErrorData duckdb::DataTable::AppendToIndexes	(	TableIndexList &	indexes,
		optional_ptr< TableIndexList >	delete_indexes,
		DataChunk &	table_chunk,
		DataChunk &	index_chunk,
		const vector< StorageIndex > &	mapped_column_ids,
		row_t	row_start,
		const IndexAppendMode	index_append_mode,
		optional_idx	active_checkpoint
	)

static

Appends a chunk with the row ids [row_start, ..., row_start + chunk.size()] to all indexes of the table. If an index is bound, it appends table_chunk. Else, it buffers index_chunk.

◆ SetAsMainTable()

void duckdb::DataTable::SetAsMainTable ( )

inline

                          {
        this->version = DataTableVersion::MAIN_TABLE;
    }

◆ SetAsDropped()

void duckdb::DataTable::SetAsDropped ( )

inline

                        {
        this->version = DataTableVersion::DROPPED;
    }

◆ IsMainTable()

bool duckdb::DataTable::IsMainTable ( ) const

inline

                             {
        return this->version == DataTableVersion::MAIN_TABLE;
    }

◆ IsRoot()

bool duckdb::DataTable::IsRoot ( ) const

inline

                        {
        return IsMainTable();
    }

◆ IndexNameIsUnique()

bool duckdb::DataTable::IndexNameIsUnique ( const string & name )

Returns true, if the index name is unique (i.e., no PK, UNIQUE, FK constraint has the same name) FIXME: This is only necessary until we treat all indexes as catalog entries, allowing to alter constraints

◆ AddIndex()

void duckdb::DataTable::AddIndex	(	const ColumnList &	columns,
		const vector< LogicalIndex > &	column_indexes,
		const IndexConstraintType	type,
		IndexStorageInfo	index_info
	)

AddIndex initializes an index and adds it to the table's index list. It is either empty, or initialized via its index storage information.

The documentation for this class was generated from the following file:

external/duckdb/duckdb.hpp

Public Member Functions

Static Public Member Functions

Public Attributes

Private Member Functions

Private Attributes

Additional Inherited Members

Detailed Description

Member Function Documentation

◆ Scan()

◆ CreateOptimisticCollection()

◆ UpdateColumn()

◆ RevertAppend()

◆ AppendToIndexes()

◆ SetAsMainTable()

◆ SetAsDropped()

◆ IsMainTable()

◆ IsRoot()

◆ IndexNameIsUnique()

◆ AddIndex()
