duckdb::Vector Class Reference

Vector of values of a specified PhysicalType. More...

#include <duckdb.hpp>

Collaboration diagram for duckdb::Vector:

Public Member Functions
DUCKDB_API	Vector (Vector &other)
	Create a vector that references the other vector.
DUCKDB_API	Vector (const Vector &other, const SelectionVector &sel, idx_t count)
	Create a vector that slices another vector.
DUCKDB_API	Vector (const Vector &other, idx_t offset, idx_t end)
	Create a vector that slices another vector between a pair of offsets.
DUCKDB_API	Vector (const Value &value)
	Create a vector of size one holding the passed on value.
DUCKDB_API	Vector (LogicalType type, idx_t capacity=STANDARD_VECTOR_SIZE)
	Create a vector of size tuple_count (non-standard)
DUCKDB_API	Vector (const VectorCache &cache)
	Create an empty standard vector with a type, equivalent to calling Vector(type, true, false)
DUCKDB_API	Vector (LogicalType type, data_ptr_t dataptr)
	Create a non-owning vector that references the specified data.
DUCKDB_API	Vector (LogicalType type, bool create_data, bool initialize_to_zero, idx_t capacity=STANDARD_VECTOR_SIZE)
	Create an owning vector that holds at most STANDARD_VECTOR_SIZE entries.
	Vector (const Vector &)=delete
DUCKDB_API	Vector (Vector &&other) noexcept
DUCKDB_API void	Reference (const Value &value)
	Create a vector that references the specified value.
DUCKDB_API void	Reference (const Vector &other)
DUCKDB_API void	Reinterpret (const Vector &other)
DUCKDB_API void	ReferenceAndSetType (const Vector &other)
	Causes this vector to reference the data held by the other vector, changes the type if required.
DUCKDB_API void	ResetFromCache (const VectorCache &cache)
DUCKDB_API void	Slice (const Vector &other, idx_t offset, idx_t end)
	Creates a reference to a slice of the other vector.
DUCKDB_API void	Slice (const Vector &other, const SelectionVector &sel, idx_t count)
	Creates a reference to a slice of the other vector.
DUCKDB_API void	Slice (const SelectionVector &sel, idx_t count)
	Turns the vector into a dictionary vector with the specified dictionary.
DUCKDB_API void	Slice (const SelectionVector &sel, idx_t count, SelCache &cache)
	Slice the vector, keeping the result around in a cache or potentially using the cache instead of slicing.
DUCKDB_API void	Dictionary (idx_t dictionary_size, const SelectionVector &sel, idx_t count)
	Turn this vector into a dictionary vector.
DUCKDB_API void	Dictionary (Vector &dict, idx_t dictionary_size, const SelectionVector &sel, idx_t count)
	Creates a reference to a dictionary of the other vector.
DUCKDB_API void	Dictionary (buffer_ptr< VectorChildBuffer > reusable_dict, const SelectionVector &sel)
	Creates a dictionary on the reusable dict.
DUCKDB_API void	Initialize (bool initialize_to_zero=false, idx_t capacity=STANDARD_VECTOR_SIZE)
DUCKDB_API string	ToString (idx_t count) const
	Converts this Vector to a printable string representation.
DUCKDB_API void	Print (idx_t count) const
DUCKDB_API string	ToString () const
DUCKDB_API void	Print () const
DUCKDB_API void	Flatten (idx_t count)
	Flatten the vector, removing any compression and turning it into a FLAT_VECTOR.
DUCKDB_API void	Flatten (const SelectionVector &sel, idx_t count)
DUCKDB_API void	ToUnifiedFormat (idx_t count, UnifiedVectorFormat &data)
DUCKDB_API void	Sequence (int64_t start, int64_t increment, idx_t count)
	Turn the vector into a sequence vector.
DUCKDB_API void	Verify (idx_t count)
DUCKDB_API void	UTFVerify (idx_t count)
DUCKDB_API void	UTFVerify (const SelectionVector &sel, idx_t count)
DUCKDB_API Value	GetValue (idx_t index) const
	Returns the [index] element of the Vector as a Value.
DUCKDB_API void	SetValue (idx_t index, const Value &val)
	Sets the [index] element of the Vector to the specified Value.
void	SetAuxiliary (buffer_ptr< VectorBuffer > new_buffer)
void	CopyBuffer (Vector &other)
DUCKDB_API void	Resize (idx_t cur_size, idx_t new_size)
	Resizes the vector.
DUCKDB_API void	FindResizeInfos (vector< ResizeInfo > &resize_infos, const idx_t multiplier)
	Returns a vector of ResizeInfo containing each (nested) vector to resize.
DUCKDB_API void	Serialize (Serializer &serializer, idx_t count, bool compressed_serialization=true)
DUCKDB_API void	Deserialize (Deserializer &deserializer, idx_t count)
idx_t	GetAllocationSize (idx_t cardinality) const
VectorType	GetVectorType () const
const LogicalType &	GetType () const
data_ptr_t	GetData () const
buffer_ptr< VectorBuffer >	GetAuxiliary ()
buffer_ptr< VectorBuffer >	GetBuffer ()
DUCKDB_API void	SetVectorType (VectorType vector_type)

Static Public Member Functions
static void	RecursiveToUnifiedFormat (Vector &input, idx_t count, RecursiveUnifiedVectorFormat &data)
	Recursively calls UnifiedVectorFormat on a vector and its child vectors (for nested types)
static DUCKDB_API void	VerifyMap (Vector &map, const SelectionVector &sel, idx_t count)
	Asserts that the CheckMapValidity returns MapInvalidReason::VALID.
static DUCKDB_API void	VerifyUnion (Vector &map, const SelectionVector &sel, idx_t count)
static DUCKDB_API void	VerifyVariant (Vector &map, const SelectionVector &sel, idx_t count)
static DUCKDB_API void	Verify (Vector &vector, const SelectionVector &sel, idx_t count)
static void	DebugTransformToDictionary (Vector &vector, idx_t count)
static void	DebugShuffleNestedVector (Vector &vector, idx_t count)

Protected Attributes
VectorType	vector_type
LogicalType	type
	The type of the elements stored in the vector (e.g. integer, float)
data_ptr_t	data
	A pointer to the data.
ValidityMask	validity
	The validity mask of the vector.
buffer_ptr< VectorBuffer >	buffer
	The main buffer holding the data of the vector.
buffer_ptr< VectorBuffer >	auxiliary

Static Private Member Functions
static Value	GetValue (const Vector &v, idx_t index)
	Returns the [index] element of the Vector as a Value.
static Value	GetValueInternal (const Vector &v, idx_t index)
	Returns the [index] element of the Vector as a Value.

Friends
struct	ConstantVector
struct	DictionaryVector
struct	FlatVector
struct	ListVector
struct	StringVector
struct	FSSTVector
struct	StructVector
struct	UnionVector
struct	SequenceVector
struct	ArrayVector
class	DataChunk
class	VectorCacheBuffer

Detailed Description

Vector of values of a specified PhysicalType.

Constructor & Destructor Documentation

Vector()

DUCKDB_API duckdb::Vector::Vector	(	LogicalType	type,
		bool	create_data,
		bool	initialize_to_zero,
		idx_t	capacity = STANDARD_VECTOR_SIZE
	)

Create an owning vector that holds at most STANDARD_VECTOR_SIZE entries.

Create a new vector If create_data is true, the vector will be an owning empty vector. If initialize_to_zero is true, the allocated data will be zero-initialized.

Member Function Documentation

Reference()

DUCKDB_API void duckdb::Vector::Reference

(

const Vector &

other

)

Causes this vector to reference the data held by the other vector. The type of the "other" vector should match the type of this vector

Reinterpret()

DUCKDB_API void duckdb::Vector::Reinterpret

(

const Vector &

other

)

Reinterpret the data of the other vector as the type of this vector Note that this takes the data of the other vector as-is and places it in this vector Without changing the type of this vector

ResetFromCache()

DUCKDB_API void duckdb::Vector::ResetFromCache

(

const VectorCache &

cache

)

Resets a vector from a vector cache. This turns the vector back into an empty FlatVector with STANDARD_VECTOR_SIZE entries. The VectorCache is used so this can be done without requiring any allocations.

Initialize()

DUCKDB_API void duckdb::Vector::Initialize	(	bool	initialize_to_zero = false,
		idx_t	capacity = STANDARD_VECTOR_SIZE
	)

Creates the data of this vector with the specified type. Any data that is currently in the vector is destroyed.

ToUnifiedFormat()

DUCKDB_API void duckdb::Vector::ToUnifiedFormat	(	idx_t	count,
		UnifiedVectorFormat &	data
	)

Creates a UnifiedVectorFormat of a vector The UnifiedVectorFormat allows efficient reading of vectors regardless of their vector type It contains (1) a data pointer, (2) a validity mask, and (3) a selection vector Access to the individual vector elements can be performed through data_pointer[sel_idx[i]]/validity[sel_idx[i]] The most common vector types (flat, constant & dictionary) can be converted to the canonical format "for free" ToUnifiedFormat was originally called Orrify, as a tribute to Orri Erling who came up with it

Verify()

DUCKDB_API void duckdb::Vector::Verify

(

idx_t

count

)

Verify that the Vector is in a consistent, not corrupt state. DEBUG FUNCTION ONLY!

SetAuxiliary()

void duckdb::Vector::SetAuxiliary ( buffer_ptr< VectorBuffer >  new_buffer )

inline

                                                                  {
        auxiliary = std::move(new_buffer);
    };

CopyBuffer()

void duckdb::Vector::CopyBuffer ( Vector &  other )

inline

                                          {
        buffer = other.buffer;
        data = other.data;
    }

GetVectorType()

VectorType duckdb::Vector::GetVectorType ( ) const

inline

                                            {
        return vector_type;
    }

GetType()

const LogicalType & duckdb::Vector::GetType ( ) const

inline

                                              {
        return type;
    }

GetData()

data_ptr_t duckdb::Vector::GetData ( ) const

inline

                                      {
        return data;
    }

GetAuxiliary()

buffer_ptr< VectorBuffer > duckdb::Vector::GetAuxiliary ( )

inline

                                                   {
        return auxiliary;
    }

GetBuffer()

buffer_ptr< VectorBuffer > duckdb::Vector::GetBuffer ( )

inline

                                                {
        return buffer;
    }

Member Data Documentation

vector_type

VectorType duckdb::Vector::vector_type

protected

The vector type specifies how the data of the vector is physically stored (i.e. if it is a single repeated constant, if it is compressed)

auxiliary

buffer_ptr<VectorBuffer> duckdb::Vector::auxiliary

protected

The buffer holding auxiliary data of the vector e.g. a string vector uses this to store strings

---

The documentation for this class was generated from the following file:

• external/duckdb/duckdb.hpp
