duckdb::Executor Class Reference

Collaboration diagram for duckdb::Executor:

Public Member Functions
	Executor (ClientContext &context)
void	Initialize (PhysicalOperator &physical_plan)
void	Initialize (unique_ptr< PhysicalOperator > physical_plan)
void	CancelTasks ()
PendingExecutionResult	ExecuteTask (bool dry_run=false)
void	WaitForTask ()
void	SignalTaskRescheduled (lock_guard< mutex > &)
void	Reset ()
vector< LogicalType >	GetTypes ()
void	PushError (ErrorData exception)
	Push a new error.
ErrorData	GetError ()
bool	HasError ()
	True if an error has been thrown.
void	ThrowException ()
void	WorkOnTasks ()
	Work on tasks for this specific executor, until there are no tasks remaining.
void	Flush (ThreadContext &context)
	Flush a thread context into the client context.
void	RescheduleTask (shared_ptr< Task > &task)
	Reschedules a task that was blocked.
void	AddToBeRescheduled (shared_ptr< Task > &task)
	Add the task to be rescheduled.
idx_t	GetPipelinesProgress (ProgressData &progress)
	Returns the progress of the pipelines.
void	CompletePipeline ()
ProducerToken &	GetToken ()
void	AddEvent (shared_ptr< Event > event)
void	AddRecursiveCTE (PhysicalOperator &rec_cte)
void	ReschedulePipelines (const vector< shared_ptr< MetaPipeline > > &pipelines, vector< shared_ptr< Event > > &events)
bool	HasResultCollector ()
	Whether or not the root of the pipeline is a result collector object.
bool	HasStreamingResultCollector ()
	Whether or not the root of the pipeline is a streaming result collector object.
unique_ptr< QueryResult >	GetResult ()
	Returns the query result - can only be used if HasResultCollector returns true.
bool	ExecutionIsFinished ()
	Returns true if all pipelines have been completed.
void	RegisterTask ()
void	UnregisterTask ()
idx_t	GetTotalPipelines () const
idx_t	GetCompletedPipelines () const

Static Public Member Functions
static Executor &	Get (ClientContext &context)

Public Attributes
ClientContext &	context

Static Public Attributes
static constexpr idx_t	WAIT_TIME = 20

Private Member Functions
bool	ResultCollectorIsBlocked ()
	Check if the streaming query result is waiting to be fetched from, must hold the 'executor_lock'.
void	InitializeInternal (PhysicalOperator &physical_plan)
void	ScheduleEvents (const vector< shared_ptr< MetaPipeline > > &meta_pipelines)
void	ScheduleEventsInternal (ScheduleEventData &event_data)
void	SchedulePipeline (const shared_ptr< MetaPipeline > &pipeline, ScheduleEventData &event_data)
bool	NextExecutor ()
shared_ptr< Pipeline >	CreateChildPipeline (Pipeline &current, PhysicalOperator &op)
void	VerifyPipeline (Pipeline &pipeline)
void	VerifyPipelines ()

Static Private Member Functions
static void	VerifyScheduledEvents (const ScheduleEventData &event_data)
static void	VerifyScheduledEventsInternal (const idx_t i, const vector< reference< Event > > &vertices, vector< bool > &visited, vector< bool > &recursion_stack)

Private Attributes
optional_ptr< PhysicalOperator >	physical_plan
unique_ptr< PhysicalOperator >	owned_plan
mutex	executor_lock
vector< shared_ptr< Pipeline > >	pipelines
	All pipelines of the query plan.
vector< shared_ptr< Pipeline > >	root_pipelines
	The root pipelines of the query.
vector< reference< PhysicalOperator > >	recursive_ctes
	The recursive CTE's in this query plan.
unique_ptr< PipelineExecutor >	root_executor
	The pipeline executor for the root pipeline.
idx_t	root_pipeline_idx
	The current root pipeline index.
unique_ptr< ProducerToken >	producer
	The producer of this query.
vector< shared_ptr< Event > >	events
	List of events.
shared_ptr< QueryProfiler >	profiler
	The query profiler.
TaskErrorManager	error_manager
	Task error manager.
atomic< idx_t >	completed_pipelines
	The amount of completed pipelines of the query.
idx_t	total_pipelines
	The total amount of pipelines in the query.
bool	cancelled
	Whether or not execution is cancelled.
PendingExecutionResult	execution_result
	The last pending execution result (if any)
shared_ptr< Task >	task
	The current task in process (if any)
unordered_map< Task *, shared_ptr< Task > >	to_be_rescheduled_tasks
	Task that have been descheduled.
std::condition_variable	task_reschedule
	The semaphore to signal task rescheduling.
atomic< idx_t >	executor_tasks
	Currently alive executor tasks.
atomic< idx_t >	blocked_thread_time
	Total time blocked while waiting on tasks. In ticks. One tick corresponds to WAIT_TIME.

Friends
class	Pipeline
class	PipelineTask
class	PipelineBuildState

Member Function Documentation

ThrowException()

void duckdb::Executor::ThrowException

(

)

Throw the exception that was pushed using PushError. Should only be called if HasError returns true

CompletePipeline()

void duckdb::Executor::CompletePipeline ( )

inline

                            {
        completed_pipelines++;
    }

GetToken()

ProducerToken & duckdb::Executor::GetToken ( )

inline

                              {
        return *producer;
    }

RegisterTask()

void duckdb::Executor::RegisterTask ( )

inline

                        {
        executor_tasks++;
    }

UnregisterTask()

void duckdb::Executor::UnregisterTask ( )

inline

                          {
        executor_tasks--;
    }

GetTotalPipelines()

idx_t duckdb::Executor::GetTotalPipelines ( ) const

inline

                                    {
        return total_pipelines;
    }

GetCompletedPipelines()

idx_t duckdb::Executor::GetCompletedPipelines ( ) const

inline

                                        {
        return completed_pipelines.load();
    }

---

The documentation for this class was generated from the following file:

• external/duckdb/duckdb.hpp
