The Pipeline class represents an execution pipeline starting at a. More...

#include <duckdb.hpp>

Inheritance diagram for duckdb::Pipeline:

Collaboration diagram for duckdb::Pipeline:

[legend]

Public Member Functions
	Pipeline (Executor &execution_context)

ClientContext &	GetClientContext ()

void	AddDependency (shared_ptr< Pipeline > &pipeline)

vector< weak_ptr< Pipeline > >	GetDependencies () const

void	Ready ()

void	Reset ()

void	ResetSink ()

void	ResetSource (bool force)

void	ClearSource ()

void	Schedule (shared_ptr< Event > &event)

void	PrepareFinalize ()

string	ToString () const

void	Print () const

void	PrintDependencies () const

bool	GetProgress (ProgressData &progress_data)
	Returns query progress.

vector< reference< PhysicalOperator > >	GetOperators ()
	Returns a list of all operators (including source and sink) involved in this pipeline.

vector< const_reference< PhysicalOperator > >	GetOperators () const

const vector< reference< PhysicalOperator > > &	GetIntermediateOperators () const

optional_ptr< PhysicalOperator >	GetSink ()

optional_ptr< PhysicalOperator >	GetSource ()

bool	IsOrderDependent () const
	Returns whether any of the operators in the pipeline care about preserving order.

idx_t	RegisterNewBatchIndex ()
	Registers a new batch index for a pipeline executor - returns the current minimum batch index.

idx_t	UpdateBatchIndex (idx_t old_index, idx_t new_index)
	Updates the batch index of a pipeline (and returns the new minimum batch index)

Public Member Functions inherited from duckdb::enable_shared_from_this< Pipeline >
shared_ptr< Pipeline >	shared_from_this ()

shared_ptr< Pipeline const >	shared_from_this () const

Public Attributes
Executor &	executor

Private Member Functions
void	ScheduleSequentialTask (shared_ptr< Event > &event)

bool	LaunchScanTasks (shared_ptr< Event > &event, idx_t max_threads)

bool	ScheduleParallel (shared_ptr< Event > &event)

Private Attributes
bool	ready
	Whether or not the pipeline has been readied.

atomic< bool >	initialized
	Whether or not the pipeline has been initialized.

optional_ptr< PhysicalOperator >	source
	The source of this pipeline.

vector< reference< PhysicalOperator > >	operators
	The chain of intermediate operators.

optional_ptr< PhysicalOperator >	sink
	The sink (i.e. destination) for data; this is e.g. a hash table to-be-built.

unique_ptr< GlobalSourceState >	source_state
	The global source state.

vector< weak_ptr< Pipeline > >	parents
	The parent pipelines (i.e. pipelines that are dependent on this pipeline to finish)

vector< weak_ptr< Pipeline > >	dependencies
	The dependencies of this pipeline.

idx_t	base_batch_index = 0
	The base batch index of this pipeline.

mutex	batch_lock
	Lock for accessing the set of batch indexes.

multiset< idx_t >	batch_indexes

Friends
class	Executor

class	PipelineExecutor

class	PipelineEvent

class	PipelineFinishEvent

class	PipelineBuildState

class	MetaPipeline

Additional Inherited Members
Protected Member Functions inherited from duckdb::enable_shared_from_this< Pipeline >
	enable_shared_from_this (enable_shared_from_this const &) noexcept

enable_shared_from_this &	operator= (enable_shared_from_this const &) noexcept

Detailed Description

The Pipeline class represents an execution pipeline starting at a.

Member Function Documentation

◆ GetSink()

optional_ptr< PhysicalOperator > duckdb::Pipeline::GetSink ( )

inline

                                             {
        return sink;
    }

◆ GetSource()

optional_ptr< PhysicalOperator > duckdb::Pipeline::GetSource ( )

inline

                                               {
        return source;
    }

Member Data Documentation

◆ batch_indexes

multiset<idx_t> duckdb::Pipeline::batch_indexes

private

The set of batch indexes that are currently being processed Despite batch indexes being unique - this is a multiset The reason is that when we start a new pipeline we insert the current minimum batch index as a placeholder Which leads to duplicate entries in the set of active batch indexes

The documentation for this class was generated from the following file:

external/duckdb/duckdb.hpp
