MetaPipeline represents a set of pipelines that all have the same sink. More...

Inheritance diagram for duckdb::MetaPipeline:

Collaboration diagram for duckdb::MetaPipeline:

[legend]

Public Member Functions
	MetaPipeline (Executor &executor, PipelineBuildState &state, optional_ptr< PhysicalOperator > sink, MetaPipelineType type=MetaPipelineType::REGULAR)
	Create a MetaPipeline with the given sink.

Executor &	GetExecutor () const
	Get the Executor for this MetaPipeline.

PipelineBuildState &	GetState () const
	Get the PipelineBuildState for this MetaPipeline.

optional_ptr< PhysicalOperator >	GetSink () const
	Get the sink operator for this MetaPipeline.

optional_ptr< Pipeline >	GetParent () const
	Get the parent pipeline.

shared_ptr< Pipeline > &	GetBasePipeline ()
	Get the initial pipeline of this MetaPipeline.

void	GetPipelines (vector< shared_ptr< Pipeline > > &result, bool recursive)
	Get the pipelines of this MetaPipeline.

void	GetMetaPipelines (vector< shared_ptr< MetaPipeline > > &result, bool recursive, bool skip)
	Get the MetaPipeline children of this MetaPipeline.

MetaPipeline &	GetLastChild ()
	Recursively gets the last child added.

const reference_map_t< Pipeline, vector< reference< Pipeline > > > &	GetDependencies () const
	Get the dependencies of the Pipelines of this MetaPipeline.

MetaPipelineType	Type () const
	Whether the sink of this pipeline is a join build.

bool	HasRecursiveCTE () const
	Whether this MetaPipeline has a recursive CTE.

void	SetRecursiveCTE ()
	Set the flag that this MetaPipeline is a recursive CTE pipeline.

void	AssignNextBatchIndex (Pipeline &pipeline)
	Assign a batch index to the given pipeline.

vector< shared_ptr< Pipeline > >	AddDependenciesFrom (Pipeline &dependant, const Pipeline &start, bool including)

void	AddRecursiveDependencies (const vector< shared_ptr< Pipeline > > &new_dependencies, const MetaPipeline &last_child)
	Recursively makes all children of this MetaPipeline depend on the given Pipeline.

void	AddFinishEvent (Pipeline &pipeline)
	Make sure that the given pipeline has its own PipelineFinishEvent (e.g., for IEJoin - double Finalize)

bool	HasFinishEvent (Pipeline &pipeline) const
	Whether the pipeline needs its own PipelineFinishEvent.

optional_ptr< Pipeline >	GetFinishGroup (Pipeline &pipeline) const
	Whether this pipeline is part of a PipelineFinishEvent.

void	Build (PhysicalOperator &op)
	Build the MetaPipeline with 'op' as the first operator (excl. the shared sink)

void	Ready () const
	Ready all the pipelines (recursively)

Pipeline &	CreatePipeline ()
	Create an empty pipeline within this MetaPipeline.

Pipeline &	CreateUnionPipeline (Pipeline &current, bool order_matters)
	Create a union pipeline (clone of 'current')

void	CreateChildPipeline (Pipeline &current, PhysicalOperator &op, Pipeline &last_pipeline)

MetaPipeline &	CreateChildMetaPipeline (Pipeline &current, PhysicalOperator &op, MetaPipelineType type=MetaPipelineType::REGULAR)
	Create a MetaPipeline child that 'current' depends on.

Public Member Functions inherited from duckdb::enable_shared_from_this< MetaPipeline >
shared_ptr< MetaPipeline >	shared_from_this ()

shared_ptr< MetaPipeline const >	shared_from_this () const

Private Attributes
Executor &	executor
	The executor for all MetaPipelines in the query plan.

PipelineBuildState &	state
	The PipelineBuildState for all MetaPipelines in the query plan.

optional_ptr< Pipeline >	parent
	Parent pipeline (optional)

optional_ptr< PhysicalOperator >	sink
	The sink of all pipelines within this MetaPipeline.

MetaPipelineType	type
	The type of this MetaPipeline (regular, join build)

bool	recursive_cte
	Whether this MetaPipeline is a the recursive pipeline of a recursive CTE.

vector< shared_ptr< Pipeline > >	pipelines
	All pipelines with a different source, but the same sink.

reference_map_t< Pipeline, vector< reference< Pipeline > > >	pipeline_dependencies
	Dependencies of Pipelines of this MetaPipeline.

vector< shared_ptr< MetaPipeline > >	children
	Other MetaPipelines that this MetaPipeline depends on.

idx_t	next_batch_index
	Next batch index.

reference_set_t< Pipeline >	finish_pipelines
	Pipelines (other than the base pipeline) that need their own PipelineFinishEvent (e.g., for IEJoin)

reference_map_t< Pipeline, Pipeline & >	finish_map
	Mapping from pipeline (e.g., child or union) to finish pipeline.

Additional Inherited Members
Protected Member Functions inherited from duckdb::enable_shared_from_this< MetaPipeline >
	enable_shared_from_this (enable_shared_from_this const &) noexcept

enable_shared_from_this &	operator= (enable_shared_from_this const &) noexcept

Detailed Description

MetaPipeline represents a set of pipelines that all have the same sink.

Constructor & Destructor Documentation

◆ MetaPipeline()

duckdb::MetaPipeline::MetaPipeline	(	Executor &	executor,
		PipelineBuildState &	state,
		optional_ptr< PhysicalOperator >	sink,
		MetaPipelineType	type = `MetaPipelineType::REGULAR`
	)

Create a MetaPipeline with the given sink.

We follow these rules when building:

For joins, build out the blocking side before going down the probe side
- The current streaming pipeline will have a dependency on it (dependency across MetaPipelines)
- Unions of this streaming pipeline will automatically inherit this dependency
Build child pipelines last (e.g., Hash Join becomes source after probe is done: scan HT for FULL OUTER JOIN)
- 'last' means after building out all other pipelines associated with this operator
- The child pipeline automatically has dependencies (within this MetaPipeline) on:
  - The 'current' streaming pipeline
  - And all pipelines that were added to the MetaPipeline after 'current'

Member Function Documentation

◆ AddDependenciesFrom()

vector< shared_ptr< Pipeline > > duckdb::MetaPipeline::AddDependenciesFrom	(	Pipeline &	dependant,
		const Pipeline &	start,
		bool	including
	)

Let 'dependant' depend on all pipeline that were created since 'start', where 'including' determines whether 'start' is added to the dependencies

◆ CreateChildPipeline()

void duckdb::MetaPipeline::CreateChildPipeline	(	Pipeline &	current,
		PhysicalOperator &	op,
		Pipeline &	last_pipeline
	)

Create a child pipeline op 'current' starting at 'op', where 'last_pipeline' is the last pipeline added before building out 'current'

The documentation for this class was generated from the following file:

external/duckdb/duckdb.cpp
