The index is an abstract base class that serves as the basis for indexes. More...

#include <duckdb.hpp>

Inheritance diagram for duckdb::BoundIndex:

[legend]

Collaboration diagram for duckdb::BoundIndex:

[legend]

Public Member Functions
	BoundIndex (const string &name, const string &index_type, IndexConstraintType index_constraint_type, const vector< column_t > &column_ids, TableIOManager &table_io_manager, const vector< unique_ptr< Expression > > &unbound_expressions, AttachedDatabase &db)

bool	IsBound () const override
	Returns true if the index is a bound index, and false otherwise.

const string &	GetIndexType () const override
	The index type (ART, B+-tree, Skip-List, ...)

const string &	GetIndexName () const override
	The name of the index.

IndexConstraintType	GetConstraintType () const override
	The index constraint type.

void	InitializeLock (IndexLock &state)
	Obtains a lock on the index.

virtual ErrorData	Append (IndexLock &l, DataChunk &chunk, Vector &row_ids)=0
	Appends data to the locked index.

ErrorData	Append (DataChunk &chunk, Vector &row_ids)
	Obtains a lock and calls Append while holding that lock.

virtual ErrorData	Append (IndexLock &l, DataChunk &chunk, Vector &row_ids, IndexAppendInfo &info)
	Appends data to the locked index and verifies constraint violations.

ErrorData	Append (DataChunk &chunk, Vector &row_ids, IndexAppendInfo &info)
	Obtains a lock and calls Append while holding that lock.

virtual void	VerifyAppend (DataChunk &chunk, IndexAppendInfo &info, optional_ptr< ConflictManager > manager)
	Verify that data can be appended to the index without a constraint violation.

virtual void	VerifyConstraint (DataChunk &chunk, IndexAppendInfo &info, ConflictManager &manager)
	Verifies the constraint for a chunk of data.

virtual void	CommitDrop (IndexLock &index_lock)=0
	Deletes all data from the index. The lock obtained from InitializeLock must be held.

void	CommitDrop () override
	Deletes all data from the index.

virtual idx_t	TryDelete (IndexLock &state, DataChunk &entries, Vector &row_identifiers, optional_ptr< SelectionVector > deleted_sel=nullptr, optional_ptr< SelectionVector > non_deleted_sel=nullptr)

idx_t	TryDelete (DataChunk &entries, Vector &row_identifiers, optional_ptr< SelectionVector > deleted_sel=nullptr, optional_ptr< SelectionVector > non_deleted_sel=nullptr)
	Obtains a lock and calls TryDelete while holding that lock.

virtual void	Delete (IndexLock &state, DataChunk &entries, Vector &row_identifiers)

void	Delete (DataChunk &entries, Vector &row_identifiers)
	Obtains a lock and calls Delete while holding that lock.

virtual ErrorData	Insert (IndexLock &l, DataChunk &chunk, Vector &row_ids)=0
	Insert a chunk.

virtual ErrorData	Insert (IndexLock &l, DataChunk &chunk, Vector &row_ids, IndexAppendInfo &info)
	Insert a chunk and verifies constraint violations.

virtual bool	MergeIndexes (IndexLock &state, BoundIndex &other_index)=0

bool	MergeIndexes (BoundIndex &other_index)
	Obtains a lock and calls MergeIndexes while holding that lock.

virtual void	Vacuum (IndexLock &l)=0

void	Vacuum ()
	Obtains a lock and calls Vacuum while holding that lock.

virtual bool	SupportsDeltaIndexes () const
	Whether or not the index supports the creation of delta indexes.

virtual unique_ptr< BoundIndex >	CreateDeltaIndex (DeltaIndexType delta_index_type) const

virtual idx_t	GetInMemorySize (IndexLock &state)=0
	Returns the in-memory usage of the index. The lock obtained from InitializeLock must be held.

idx_t	GetInMemorySize ()
	Returns the in-memory usage of the index.

virtual void	Verify (IndexLock &l)=0
	Returns the string representation of an index, or only traverses and verifies the index.

void	Verify ()
	Obtains a lock and calls VerifyAndToString.

virtual string	ToString (IndexLock &l, bool display_ascii=false)=0
	Returns the string representation of an index.

string	ToString (bool display_ascii=false)
	Obtains a lock and calls ToString.

virtual void	VerifyAllocations (IndexLock &l)=0
	Ensures that the node allocation counts match the node counts.

void	VerifyAllocations ()
	Obtains a lock and calls VerifyAllocations.

virtual void	VerifyBuffers (IndexLock &l)
	Verify the index buffers.

void	VerifyBuffers ()
	Obtains a lock and calls VerifyBuffers.

bool	IndexIsUpdated (const vector< PhysicalIndex > &column_ids) const
	Returns true if the index is affected by updates on the specified column IDs, and false otherwise.

virtual IndexStorageInfo	SerializeToDisk (QueryContext context, const case_insensitive_map_t< Value > &options)
	Serializes index memory to disk and returns the index storage information.

virtual IndexStorageInfo	SerializeToWAL (const case_insensitive_map_t< Value > &options)
	Serializes index memory to the WAL and returns the index storage information.

void	ExecuteExpressions (DataChunk &input, DataChunk &result)
	Execute the index expressions on an input chunk.

virtual string	GetConstraintViolationMessage (VerifyExistenceType verify_type, idx_t failed_index, DataChunk &input)=0
	Throw a constraint violation exception.

void	ApplyBufferedReplays (const vector< LogicalType > &table_types, BufferedIndexReplays &buffered_replays, const vector< StorageIndex > &mapped_column_ids)

Public Member Functions inherited from duckdb::Index
bool	IsUnique () const
	Returns unique flag.

bool	IsPrimary () const
	Returns primary key flag.

bool	IsForeign () const
	Returns foreign key flag.

const vector< column_t > &	GetColumnIds () const

const unordered_set< column_t > &	GetColumnIdSet () const

template<class TARGET >
TARGET &	Cast ()

template<class TARGET >
const TARGET &	Cast () const

Static Public Member Functions
static string	AppendRowError (DataChunk &input, idx_t index)

Public Attributes
vector< PhysicalType >	types
	The physical types stored in the index.

vector< LogicalType >	logical_types
	The logical types of the expressions.

string	name
	The name of the index.

string	index_type
	The index type (ART, B+-tree, Skip-List, ...)

IndexConstraintType	index_constraint_type
	The index constraint type.

vector< unique_ptr< Expression > >	unbound_expressions

DeltaIndexType	delta_index_type = DeltaIndexType::NONE
	Whether or not this is a delta index - and if it is, which type it is.

Public Attributes inherited from duckdb::Index
TableIOManager &	table_io_manager
	Associated table io manager.

AttachedDatabase &	db
	Attached database instance.

Protected Attributes
mutex	lock
	Lock used for any changes to the index.

vector< unique_ptr< Expression > >	bound_expressions

Protected Attributes inherited from duckdb::Index
vector< column_t >	column_ids

unordered_set< column_t >	column_id_set
	Unordered set of column_ids used by the Index.

Private Member Functions
unique_ptr< Expression >	BindExpression (unique_ptr< Expression > expr)
	Bind the unbound expressions of the index.

Private Attributes
ExpressionExecutor	executor
	Expression executor to execute the index expressions.

Additional Inherited Members
Protected Member Functions inherited from duckdb::Index
	Index (const vector< column_t > &column_ids, TableIOManager &table_io_manager, AttachedDatabase &db)

Detailed Description

The index is an abstract base class that serves as the basis for indexes.

Member Function Documentation

◆ IsBound()

bool duckdb::BoundIndex::IsBound ( ) const

inlineoverridevirtual

Returns true if the index is a bound index, and false otherwise.

Implements duckdb::Index.

                                  {
        return true;
    }

◆ GetIndexType()

const string & duckdb::BoundIndex::GetIndexType ( ) const

inlineoverridevirtual

The index type (ART, B+-tree, Skip-List, ...)

Implements duckdb::Index.

                                                {
        return index_type;
    }

◆ GetIndexName()

const string & duckdb::BoundIndex::GetIndexName ( ) const

inlineoverridevirtual

The name of the index.

Implements duckdb::Index.

                                                {
        return name;
    }

◆ GetConstraintType()

IndexConstraintType duckdb::BoundIndex::GetConstraintType ( ) const

inlineoverridevirtual

The index constraint type.

Implements duckdb::Index.

                                                           {
        return index_constraint_type;
    }

◆ Append() [1/2]

virtual ErrorData duckdb::BoundIndex::Append	(	IndexLock &	l,
		DataChunk &	chunk,
		Vector &	row_ids
	)

pure virtual

Appends data to the locked index.

Implemented in duckdb::ART.

◆ Append() [2/2]

virtual ErrorData duckdb::BoundIndex::Append	(	IndexLock &	l,
		DataChunk &	chunk,
		Vector &	row_ids,
		IndexAppendInfo &	info
	)

virtual

Appends data to the locked index and verifies constraint violations.

Reimplemented in duckdb::ART.

◆ VerifyAppend()

virtual void duckdb::BoundIndex::VerifyAppend	(	DataChunk &	chunk,
		IndexAppendInfo &	info,
		optional_ptr< ConflictManager >	manager
	)

virtual

Verify that data can be appended to the index without a constraint violation.

Reimplemented in duckdb::ART.

◆ VerifyConstraint()

virtual void duckdb::BoundIndex::VerifyConstraint	(	DataChunk &	chunk,
		IndexAppendInfo &	info,
		ConflictManager &	manager
	)

virtual

Verifies the constraint for a chunk of data.

Reimplemented in duckdb::ART.

◆ CommitDrop() [1/2]

virtual void duckdb::BoundIndex::CommitDrop ( IndexLock & index_lock )

pure virtual

Deletes all data from the index. The lock obtained from InitializeLock must be held.

Implemented in duckdb::ART.

◆ CommitDrop() [2/2]

void duckdb::BoundIndex::CommitDrop ( )

overridevirtual

Deletes all data from the index.

Implements duckdb::Index.

◆ TryDelete()

virtual idx_t duckdb::BoundIndex::TryDelete	(	IndexLock &	state,
		DataChunk &	entries,
		Vector &	row_identifiers,
		optional_ptr< SelectionVector >	deleted_sel = `nullptr`,
		optional_ptr< SelectionVector >	non_deleted_sel = `nullptr`
	)

virtual

Delete a chunk of entries from the index. The lock obtained from InitializeLock must be held. Returns the amount of rows successfully deleted from the index. If either deleted_sel or non_deleted_sel are provided the exact rows that were (not) deleted are written there

Reimplemented in duckdb::ART.

◆ Delete()

virtual void duckdb::BoundIndex::Delete	(	IndexLock &	state,
		DataChunk &	entries,
		Vector &	row_identifiers
	)

virtual

Delete a chunk of entries from the index. The lock obtained from InitializeLock must be held. Throws an error if not all rows are deleted

◆ Insert() [1/2]

virtual ErrorData duckdb::BoundIndex::Insert	(	IndexLock &	l,
		DataChunk &	chunk,
		Vector &	row_ids
	)

pure virtual

Insert a chunk.

Implemented in duckdb::ART.

◆ Insert() [2/2]

virtual ErrorData duckdb::BoundIndex::Insert	(	IndexLock &	l,
		DataChunk &	chunk,
		Vector &	row_ids,
		IndexAppendInfo &	info
	)

virtual

Insert a chunk and verifies constraint violations.

Reimplemented in duckdb::ART.

◆ MergeIndexes()

virtual bool duckdb::BoundIndex::MergeIndexes	(	IndexLock &	state,
		BoundIndex &	other_index
	)

pure virtual

Merge another index into this index. The lock obtained from InitializeLock must be held, and the other index must also be locked during the merge

Implemented in duckdb::ART.

◆ Vacuum()

virtual void duckdb::BoundIndex::Vacuum ( IndexLock & l )

pure virtual

Performs a full traversal of the ART while vacuuming the qualifying nodes. The lock obtained from InitializeLock must be held.

Implemented in duckdb::ART.

◆ SupportsDeltaIndexes()

virtual bool duckdb::BoundIndex::SupportsDeltaIndexes ( ) const

virtual

Whether or not the index supports the creation of delta indexes.

Reimplemented in duckdb::ART.

◆ CreateDeltaIndex()

virtual unique_ptr< BoundIndex > duckdb::BoundIndex::CreateDeltaIndex ( DeltaIndexType delta_index_type ) const

virtual

Creates a delta index - an empty copy of the index with the same schema, etc This will only be called if SupportsDeltaIndexes returns true

Reimplemented in duckdb::ART.

◆ GetInMemorySize()

virtual idx_t duckdb::BoundIndex::GetInMemorySize ( IndexLock & state )

pure virtual

Returns the in-memory usage of the index. The lock obtained from InitializeLock must be held.

Implemented in duckdb::ART.

◆ Verify()

virtual void duckdb::BoundIndex::Verify ( IndexLock & l )

pure virtual

Returns the string representation of an index, or only traverses and verifies the index.

Implemented in duckdb::ART.

◆ ToString()

virtual string duckdb::BoundIndex::ToString	(	IndexLock &	l,
		bool	display_ascii = `false`
	)

pure virtual

Returns the string representation of an index.

Implemented in duckdb::ART.

◆ VerifyAllocations()

virtual void duckdb::BoundIndex::VerifyAllocations ( IndexLock & l )

pure virtual

Ensures that the node allocation counts match the node counts.

Implemented in duckdb::ART.

◆ VerifyBuffers()

virtual void duckdb::BoundIndex::VerifyBuffers ( IndexLock & l )

virtual

Verify the index buffers.

Reimplemented in duckdb::ART.

◆ SerializeToDisk()

virtual IndexStorageInfo duckdb::BoundIndex::SerializeToDisk	(	QueryContext	context,
		const case_insensitive_map_t< Value > &	options
	)

virtual

Serializes index memory to disk and returns the index storage information.

Reimplemented in duckdb::ART.

◆ SerializeToWAL()

virtual IndexStorageInfo duckdb::BoundIndex::SerializeToWAL ( const case_insensitive_map_t< Value > & options )

virtual

Serializes index memory to the WAL and returns the index storage information.

Reimplemented in duckdb::ART.

◆ GetConstraintViolationMessage()

virtual string duckdb::BoundIndex::GetConstraintViolationMessage	(	VerifyExistenceType	verify_type,
		idx_t	failed_index,
		DataChunk &	input
	)

pure virtual

Throw a constraint violation exception.

Implemented in duckdb::ART.

◆ ApplyBufferedReplays()

void duckdb::BoundIndex::ApplyBufferedReplays	(	const vector< LogicalType > &	table_types,
		BufferedIndexReplays &	buffered_replays,
		const vector< StorageIndex > &	mapped_column_ids
	)

Replay index insert and delete operations buffered during WAL replay. table_types has the physical types of the table in the order they appear, not logical (no generated columns). mapped_column_ids contains the sorted order of Indexed physical column ID's (see unbound_index.hpp comments).

Member Data Documentation

◆ unbound_expressions

vector<unique_ptr<Expression> > duckdb::BoundIndex::unbound_expressions

The vector of unbound expressions, which are later turned into bound expressions. We need to store the unbound expressions, as we might not always have the context available to bind directly. The leaves of these unbound expressions are BoundColumnRefExpressions. These BoundColumnRefExpressions contain a binding (ColumnBinding), and that contains a table_index and a column_index. The table_index is a dummy placeholder. The column_index indexes the column_ids vector in the Index base class. Those column_ids store the physical table indexes of the Index, and we use them when binding the unbound expressions.

◆ bound_expressions

vector<unique_ptr<Expression> > duckdb::BoundIndex::bound_expressions

protected

The vector of bound expressions to generate the Index keys based on a data chunk. The leaves of the bound expressions are BoundReferenceExpressions. These BoundReferenceExpressions contain offsets into the DataChunk to retrieve the columns for the expression. With these offsets into the DataChunk, the expression executor can now evaluate the expression on incoming data chunks to generate the keys.

The documentation for this class was generated from the following file:

external/duckdb/duckdb.hpp

Public Member Functions

Static Public Member Functions

Public Attributes

Protected Attributes

Private Member Functions

Private Attributes

Additional Inherited Members

Detailed Description

Member Function Documentation

◆ IsBound()

◆ GetIndexType()

◆ GetIndexName()

◆ GetConstraintType()

◆ Append() [1/2]

◆ Append() [2/2]

◆ VerifyAppend()

◆ VerifyConstraint()

◆ CommitDrop() [1/2]

◆ CommitDrop() [2/2]

◆ TryDelete()

◆ Delete()

◆ Insert() [1/2]

◆ Insert() [2/2]

◆ MergeIndexes()

◆ Vacuum()

◆ SupportsDeltaIndexes()

◆ CreateDeltaIndex()

◆ GetInMemorySize()

◆ Verify()

◆ ToString()

◆ VerifyAllocations()

◆ VerifyBuffers()

◆ SerializeToDisk()

◆ SerializeToWAL()

◆ GetConstraintViolationMessage()

◆ ApplyBufferedReplays()

Member Data Documentation

◆ unbound_expressions

◆ bound_expressions
